If you are looking for an affordable road bike with a super comfortable geometry and ample tyre clearance so that you could even run 35 mm wide tyres (including fenders), then look no further. The SCULTURA ENDURANCE 300 combines a beautifully made 6066 aluminium frame, featuring the same comfort orientated geometry as its carbon relatives and a full carbon fork for added vibration absorption with a reliable Tiagra 10-speed groupset.
The SCULTURA ENDURANCE is the perfect choice for more leisure-focused cyclists who want to enjoy long hours in the saddle while being comfortable and relaxed on the bike. Wide tyres offer plenty of comfort, even on the most pothole-littered country lanes, while a longer head tube provides a more relaxed riding position. An instant hit with the international cycling press and besides being given a 'comfort' award by RennRad, it also managed to get a long list of compliments like 'excellent comfort', ‘confidence inspiring', 'lively feel' and 'enjoyable' by reference cycling media such as Gran Fondo, Cycling news, Cycling tips and Road.cc. Compared to its namesake, the SCULTURA, the ENDURANCE has a more comfort-orientated geometry, plenty of tyre clearance and seamless integration of the latest standards. It sits between the road-biased SCULTURA on one side and the gravel/adventure SILEX on the other, while the SCULTURA ENDURANCE GR lineup offers gravel-racing focused options with off-road ready tyres and flared handlebars.
Component | Specification |
Frame |
SCULTURA ENDURANCE LITE
|
Frame Sizes |
XXS, XS, S, SM, L, XL
|
Color |
SILK FOG GREEN (GREEN/SILVER)
|
Fork |
SCULTURA ENDURANCE CF3 DISC
|
Brakes |
Shimano Tiagra, Hydraulic disc
|
Rotors |
Shimano RT10, 160mm
|
Brake Lever |
Shimano Tiagra
|
Headset |
ACROS MERIDA INTERNAL, neck width and splitting
|
Handlebar |
MERIDA EXPERT SL
|
Handlebar Stem |
MERIDA TEAM CC III
|
Grip |
MERIDA ROAD Expert
|
Front Derailleur |
Shimano Tiagra
|
Rear Derailleur |
Shimano Tiagra, GS
|
Shifters |
Shimano Tiagra disc
|
Seat Post |
MERIDA COMP CC
|
Seat Clamp |
MERIDA EXPERT
|
Saddle |
MERIDA COMP SL
|
Chain | KMC X10 |
Crank |
Shimano Tiagra, 50-34 teeth, Lengths: 165 mm (XXS), 170 mm (XS-S), 172.5 mm (M-L), 175 mm (XL)
|
Freewheel |
Shimano PGS800, 12-32 teeth, 10 speed
|
Bottom Bracket |
Shimano SM-BB72-41B, Pressfit 86.5
|
Hubs |
Joytech D871S (front) / Joytech D872TS-R (rear)
|
Rims |
MERIDA EXPERT SLII
|
Tyre Front |
Maxxis Detonator, 700x32C, fold
|
Tyre Rear |
Maxxis Detonator, 700x32C, fold
|
Axles |
MERIDA COMP TR, Including removable lever, 6mm allen key
|
Spokes | Black stainless |
Approx. Weight | 9.6 kg |
Weight Disclaimer |
Weight may vary depending on bike size, finish or possible specification change due to supply chain issues
|
FRAME SIZE | Height (CM) |
XS | 158-167 |
S | 163-172 |
S/M | 168-177 |
M/L | 173-182 |
L | 178-187 |
XXL | 183-193 |
Frame Size | 4XS | 3XS | XXS | XS | S | M | L | XL |
Tyre Sizes | 28" | 28" | 28" | 28" | 28" | 28" | 28" | 28" |
ST Seat Tube [mm] | 380 | 410 | 440 | 470 | 490 | 510 | 530 | 560 |
TT Top Tube [mm] | 507 | 507 | 515 | 524 | 538 | 553 | 568 | 583 |
CS Chain Stay Length [mm] | 418 | 418 | 418 | 418 | 418 | 418 | 418 | 418 |
HTA Head Tube Angle [°] | 70 | 70 | 70.5 | 71 | 72 | 73 | 73.5 | 73.5 |
STA Seat Tube Angle [°] | 74.5 | 74.5 | 74 | 74 | 73.5 | 73.5 | 73.5 | 73.5 |
BD Bottom Bracket Drop [mm] | 70 | 70 | 66 | 66 | 66 | 66 | 66 | 66 |
HT Head Tube [mm] | 125 | 130 | 140 | 152 | 161 | 177 | 197 | 222 |
FL Fork Length [mm] | 380 | 380 | 380 | 380 | 380 | 380 | 380 | 380 |
R Reach [mm] | 360 | 360 | 360 | 366 | 376 | 380 | 389 | 397 |
S Stack [mm] | 528 | 532 | 539 | 552 | 565 | 584 | 603 | 629 |
WB Wheel Base [mm] | 990 | 991 | 992 | 997 | 1001 | 1001 | 1016 | 1026 |
SH Stand Over Height [mm] | 656 | 680 | 708 | 734 | 752 | 770 | 790 | 818 |
