Trek Checkpoint SL 5 AXS Gen 3 - Lava/Black Olive
Trek
IN-STORE PICKUP ONLY
Trek Bicycles & Bontrager Spares/Accessories are only available for in-store pickup from our Pune Bike Shop.
Please Call or Whatsapp (+91) 7020425618 to talk to our Product Specialists.
The Checkpoint SL 5 AXS Gen 3 is an adventure-ready carbon gravel bike built to roll into the distant horizon. Its lightweight carbon frame is designed with comfort-focused geometry, room for beefy 50 mm tyres (as measured), and plenty of frame and fork mounts. Plus, IsoSpeed comfort technology helps soak up jarring road vibrations, helping you float over chatter and potholes. It comes equipped with a wireless 12-speed SRAM Apex XPLR AXS drivetrain to deliver plenty of gears for exploring the dusty road.
You want a carbon gravel bike for exploring the beyond, and want to save on parts you can upgrade over time. You want the gravel-smoothing benefits of IsoSpeed tech that soaks up chatter from below so you can ride stronger for longer and plenty of mounts to carry all your gear and hydration.
A 500 Series OCLV Carbon frame with a carbon fork, internal downtube storage, frame and fork mounts, and clearance for 50 mm tyres (as measured). A 12-speed 1x SRAM Apex XPLR AXS fully wireless drivetrain, hydraulic disc brakes, carbon seat post, and Tubeless Ready Bontrager Paradigm SL wheels with 42 mm tyres.
When you're ready to load up and explore the road less travelled, reach for the Checkpoint SL 5 AXS Gen 3. This capable and comfortable gravel bike balances price and performance with a blend of components that deliver reliably and a frame that's packed with road-smoothing features.
| *Please note - spec applies to all sizes unless listed separately | |
| Frameset | |
| Frame | 500 Series OCLV Carbon, IsoSpeed, downtube storage door, hidden mudguard mounts, rack mounts, integrated frame bag mounts, invisible cable routing, T47, flat-mount disc, integrated chainkeeper, removable FD hanger, UDH, 142x12 mm chamfered thru axle |
| Fork | Checkpoint full carbon, tapered carbon steerer, mudguard mounts, triple rack mounts, flat-mount disc, 12x100 mm chamfered thru axle |
| Max compatible fork travel | 40 mm (XS: compatible with rigid fork only) See Checkpoint SL Gen 3 FAQ for compatible options |
| Weight | |
| Weight | ML - 9.50 kg / 20.95 lbs (with TLR sealant, no tubes) |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| E-system | |
| Battery | SRAM eTap battery pack (with charger) |
| Drivetrain | |
|
*Shifter
|
Size: S, M, ML, L SRAM Apex, 12-speed |
| Size: S, M, ML, L SRAM Apex AXS, 12-speed |
|
| Rear derailleur | SRAM Apex XPLR eTap AXS, 44T max cog |
|
*Crank
|
Size: S SRAM Apex 1, 40T, DUB Wide, 165 mm length |
| Size: M SRAM Apex 1, 40T, DUB Wide, 170 mm length |
|
| Size: ML, L SRAM Apex 1, 40T, DUB Wide, 172.5 mm length |
|
| Bottom bracket | SRAM DUB, T47 threaded, internal bearing |
| Cassette | SRAM XPLR PG-1231, 11-44, 12-speed |
| Chain | SRAM Apex, 12-speed |
| Max. chainring size | 1x:44 2x: 46/30 |
| Wheels | |
| Wheel front | Bontrager Paradigm SL, Tubeless Ready, 21 mm rim width, 100x12 mm thru axle |
| Wheel rear | Bontrager Paradigm SL, Tubeless Ready, 21 mm rim width, 142x12 mm thru axle |
| Skewer front | Bontrager Switch chamfered thru axle, removable lever |
| Skewer rear | Bontrager Switch chamfered thru axle, removable lever |
| Tyre | Bontrager Girona RSL, Tubeless Ready, GR puncture protection, aramid bead, 220 tpi, 700x42 mm |
| Tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| Rim strip | Bontrager TLR |
| Max tyre size | 50 mm without mudguards, 42 mm with mudguards |
| Components | |
|
*Saddle
|
Size: S Verse Short Comp, steel rails, 155 mm width |
| Size: M, ML, L Verse Short Comp, steel rails, 145 mm width |
|
| Seatpost | Bontrager carbon, 27.2 mm, 8 mm offset, 330 mm length |
|
*Handlebar
|
Size: S, M Bontrager Elite Gravel, alloy, 42 cm width |
| Size: ML, L Bontrager Elite Gravel, alloy, 44 cm width |
|
| Handlebar tape | Bontrager Supertack Perf tape |
|
*Stem
|
Size: S Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length |
| Size: M, ML Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length |
|
| Size: L Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length |
|
| Brake rotor | SRAM Paceline, rounded, CentreLock, 160 mm |
| Rotor size | Max brake rotor sizes: 180mm front and rear |
| Accessories | |
| Bag | Bontrager BITS Internal Frame Storage Bag |
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
How tall are you?
To measure your height, stand up straight, barefoot, with your back, heels, shoulders and head all touching a wall. While looking straight ahead, place a book or straight edge on your head and slowly push it against the wall. Your straight edge should be parallel with the floor. Mark the spot where the bottom of the book is touching the wall. The distance from the marked spot to the floor is your height.
What is your inside leg?
How to measure: Stand barefoot with your back straight and against a wall. Tuck a ruler or something that extends to the floor between your legs. Using both hands, and keeping it level, pull the ruler up into your crotch as if you were sitting on the saddle. Measure the distance from the top edge of the ruler to the ground to find your inside leg measurement. Your inside leg is very important to your final bike size so please measure carefully.
| Size | XS (49cm) | S (49-52cm) | M (52-54cm) | ML (56cm) | L (58cm) | XL (61cm) |
| Rider Height | 143 - 158 cm 4'8" - 5'2" |
158 - 164 cm 5'2" - 5'5" |
164 - 177 cm 5'5" - 5'10" |
177 - 188 cm 5'10" - 6'2" |
188 - 194 cm 6'2" - 6'4" |
194 - 203 cm 6'4" - 6'8" |
| Inseam | 67 - 74 cm 26" - 29" |
74 - 77 cm 29" - 30" |
77 - 83 cm 30" - 33" |
83 - 88 cm 33" - 35" |
88 - 91 cm 35" - 36" |
91 - 95 cm 36" - 37" |
| Frame size number | 52 cm | 54 cm | 56 cm | 58 cm |
| Frame size letter | S | M | ML | L |
| Wheel size | 700c | 700c | 700c | 700c |
| A — Seat tube | 48 | 50.5 | 53 | 55 |
| B — Seat tube angle | 74.0° | 73.3° | 73.3° | 73.3° |
| Effective seat tube angle | 73.0° | 72.8° | 72.8° | 72.8° |
| C — Head tube length | 10.6 | 13 | 15.1 | 17.1 |
| D — Head angle | 71.4° | 71.6° | 72.0° | 72.1° |
| E — Effective top tube | 54.7 | 56.6 | 57.8 | 58.9 |
| G — Bottom bracket drop | 7.6 | 7.6 | 7.6 | 7.6 |
| H — Chainstay length | 43 | 43 | 43 | 43 |
| I — Offset | 4.9 | 4.9 | 4.9 | 4.9 |
| J — Trail | 6.8 | 6.8 | 6.4 | 6.4 |
| K — Wheelbase | 102.2 | 103.4 | 104.2 | 105.2 |
| L — Standover | 77.2 | 79.9 | 81.3 | 83.7 |
| M — Frame reach | 38.6 | 39.1 | 39.7 | 40.2 |
| N — Frame stack | 55.6 | 57.9 | 60.1 | 62 |
